دارات تحكم حرارة ورطوبة للفقاسات

 Temperature & Humidity

Control









مركز الموسوعة الالكترونية

دمشق - شارع مسلم البارودي - سورية

 هاتف:2221161 - 2251161 - 0969515995



لمعرفة الأسعار الاتصال مع قسم المبيعات بالايميل أو واتس أب



e-mail: matni3008@gmail.com



Whatsapp: 0969515995 واتس








TH67   STC-3018 12V      دارة تحكم حرارتين

Dual Digital Temperature Controller STC-3018 12V 24V 110-220V  Celsius & Fahrenheit Thermo regulator Thermostat Switch

Temperature measuring range: -55 C ~ 120 C  -66F~248F
Resolution: 0.1 C
Accuracy:1 C


TH66 STC-3008 12V    دارة تحكم حرارة

 Temperature measuring range: -55 C ~ 120 C
 Resolution: 0.1 C
 Accuracy:1 C

فيديو :

https://www.youtube.com/watch?v=ocTdgqJ-qDk








TH63  ST-3012    دارة تحكم حرارتين

ST3012 Microcomputer Digital Display Intelligent Dual Control Electronic Temperature Controller

دارة تحكم حرارة ST3012 للفقاسات والمشاتل وغرف التبريد ومستودعات المواد الغذائية .. تتحكم بدرجتي حرارة ضمن المجال ناقص ٥٠ درجة وحتى زايد ١١٠ درجة ..

تعمل على البطارية 12V

لأي استفسار رسالة واتس الى قسم المبيعات

0969515995

فيديو



*Technical parameters.

Temperature control range:-50℃~110℃

Temperature measurement error:0.5℃

Sensor model:ntc(10K/3435)

Control precision:DC12V/DC24V/AC110V~230V(can be choose)

Working current:MAX200Ma

Relay contact current:AC5A/220V




TH59  دارة تحكم رطوبة

H-W3005 Humidity Temperature Controller 12V




TH54  دارة تحكم حرارة ورطوبة

High Precision Digital Double Output Automatic Constant Temperature And Humidity Temperature Controller Of ZFX-M452




TH52      وصلة كهربائية + دارة تحكم حرارة

Digital temperature controller  W-2002



Temperature measurement range: -50-110C
Temperature control range: -50-110C
Control accuracy: 0.1C
Measurement input: NTC10K
Output Type: Direct Output
Output capacity: MAX10A
Input power: 110-220V
Power: 250V/10A

Instructions:

Up button: Press once to display the start temperature,

 long press set start temperature
Down button: Press once to display stop temperature,

 long press to set stop temperature


TH50 مقياس حرارة ورطوبة رقمي

FY-12 Digital Humidity Thermometer



Temperature Range: -50 ~70 C

Humidity Range: 10% RH ~ 99% RH

Temperature Accuracy: 1 C

Humidity Accuracy: 5%

Humidity Display Resolution: 1% RH

Working Voltage: 1.5V, or LR44 batteryr

Sampling Period: 10 S


TH49  وصلة كهربائية + دارة تحكم حرارة

MH-2000 AC90V~ 250V

Digital Temperature Controller

Specifications:

  • Color: Black
  • Material: PC
  • Working Voltage: 90V~250V
  • Rated Current: 10A
  • Power Consumption: ≤3W
  • Power Consumption of Standing by: ≤0.5W
  • Precision of Temperature Control: 0.1degrees
  • Resolution: 0.1degrees
  • Measurement Error: 0.3degrees
  • Control Range:  -40~120degrees
  • Slewing Range of Temperature: 0.1~30
  • degrees(adjustable)
  • Working Temperature: -20~70degrees
  • Working Humidity: 90% RH Non Condensing
  • Temperature sensor: NTC 25degrees
  • =10K B3435 1% (1.48m Line)
  • Length of Power Line: 1.45m / 57.1in
  • Relay: 10A / AC220V
  • Item Size: 15.5 * 6 * 2.8cm / 6.1 * 2.4 * 1.1in
  • Item Weight: 245.2g / 8.6oz
  • Package Size: 21.5 * 11 * 3.5cm /
  • 8.5 * 4.3 * 1.4in
  • Package Weight: 317g / 11.2oz



TH44  دارة تحكم بالحرارة

XH-W3001 12V Digital Control Microcomputer  Switch Temperature




TH37   دارة تحكم حرارة ورطوبة

ZFX-W1013 Intelligent Digital display

temperature and humidity controller dual-use greenhouse incubation and humidity control






TH36 دارة تحكم حرارة

XH-W1401 Intelligent Digital Thermostat Module

Temperature Control H02 DC 9V-15V


TH34 دارة حساس رطوبة

5V Humidity Sensitive Switch Relay Module


TH32 دارة تحكم بالرطوبة والحرارة

DC 5V~24V Digital Intelligent Temperature & Humidity Controller  Relay with LED Indicator Alarm Function

This product can control temperature &

humidity and display real-time temperature and

humidity. 5 function modes(with indicator):

high temperature start-cooling mode, low

temperature start-heating mode, high

humidity start-dehumidification mode,

low humidity start-humidification mode

and temperature alarm mode. It's suitable

for greenhouse, incubator, barton, etc.

Features:
Measure and display temperature & humidity.
5 function modes: cooling, heating, dehumidification,

humidification and temperature alarm.
Temperature unit-conversion between C and F.
With highlight LED display and working indicator,

convenient for operation.
Store setting parameters automatically when

power off.
Reverse polarity protection: the controller

will not work if connected reversely.
Wide input voltage range DC 5V~24V,

dual 10A relay for high power output.
Suitable for controlling the temperature

and humidity in greenhouse, incubator, barton, etc.

User Manual:
https://www.dropbox.com/s/

7g5areea3ln45hc/E0472-User%

20Manual.docx?dl=0

Specifications:
Temperature Measuring Range: -40C~80C
Humidity Measuring Range: 0%RH~99.9%RH
Temperature Resolution: 0.1C
Humidity Resolution: 0.1%RH
Measuring Accuracy: (+/-)3%RH, (+/-)0.5%C
Control Accuracy: 0.1%RH, (+/-)0.1%C
Refresh Rate: 1s
Input Voltage: DC 5V~24V
Measurement Input: AM2301 Temperature and Humidity

Integrated Sensor
Output: Dual 10A Relay
Environmental Requirement: -10C~60C, 20%~85%

Humidity
Quiescent Current: ≤20mA
Pull Current: ≤50mA
Board Size: 90 * 60 * 20mm / 3.54 * 2.36 * 0.8in
Board Weight: 54g/ 1.93oz
Package Size: Approx. 13 * 8 * 2.5cm

/ 5.12 * 3.15 * 0.98in
Package Weight: 72g / 2.56oz




TH21    دارة تحكم حرارة تبين درجة الحرارة الحالية ودرجة الحرارة

التي تم تعييرها

HX-W1411 Digital Temperature Controller 3 displays

DC12V

Using MCU control system and highly accurate

temperature detection probe, this product is clearly

better than other products of the same category in terms

of temperature control performance and accuracy. This

product uses the design of three display windows, which

can perform real-time display for start and stop value.

Moreover, it has other functions such as intermittent work,

time switch, etc. It can be widely used in greenhouse

cultivation, aquaculture and animal husbandry,

computer lab temperature control and other fields.

It is also a great helper for household life!

Specifications:

Model: XH-1411
Voltage: DC 12V
Power: 10A
Temperature measurement range: -55~+120 Celsius

degrees
Temperature measurement accuracy: 0.3 Celsius

degrees
Resolution: 0.1 Celsius degrees
Temperature control range: -19~99 Celsius degrees
Control accuracy: 1 Celsius degree
Temperature measurement probe: NTC10K/B3950

standard 1m water-proof probe
Power supply voltage: DC 12V
Display color: red, green, blue, yellow (alternative)
Applicable environment: -25~55 Celsius degrees,

humidity 20%~85% (no condensation)
Output type: 10A relay output
Appearance size: 90*60mm
Open hole size: 70*50mm

Instruction:

1. Plug the plug of this product to a household socket.

If the screen displays temperature, it means the power

supply has been correctly connected.
2. Put the temperature control probe into the places

that need temperature control, and set the start and

stop temperature according to your needs.
3. Plug the plugs of heating and refrigeration

devices to the socket of temperature controller,

and then you can achieve temperature control.

Operation instructions:

After power-on, if the temperature is within the range,

 you should immediately start the output and make it

 stop when it reaches the set value.
Start temperature For example, if you want to control

water boiling to stop at 60 Celsius degrees and start

over at 45 Celsius degrees, then you should set the

start value as 45 and stop value as 60.
Start temperature >stop temperature: refrigeration mode
For example, in summer, you want to control the

greenhouse to start the scavenger fan when the

temperature is higher than 35 Celsius degrees

and stop at 32 Celsius degrees, then you should

set the start value as 35 and stop value as 32.
SET: function button/power-on & power-off button
In the state of power-on, you can switch off by a

long press for 3 seconds. After switched off,

 it will still remain power-off if there is no power supply.
In the state of power-off, you can switch on by

pressing SET once. After switched on, it will still

remain power-on if there is no power supply.
In the state of normal temperature control, you can switch

between F-1~F-3 by pressing SET once.
    F-1 intermittent work mode unit: minute left: start

minute right: stop minute
    F-2 time switch left: hour right: minute 99h59mins max
    F-3 time switch left: hour right: minute 99h59mins max

Temperature correction: Enter the temperature

correction function by removing the controller plug

and pressing SET to supply power. The screen

displays -00--. You can increase or decrease

temperature on the basis of the original temperature,

maximum range -9.9~+99. After correction:

Real-time temperature = the temperature before

correction + the corrected value
Press (start+-) power-on to enter self-check function;

Press (stop+-) power-on to restore factory settings.

Restore factory settings:

If there is some setting mistake or setting disorder,

 you can press the two stop buttons to restore

factory settings.
When the screen displays 88-888-88, and the

 buzz gives out a long sound, it means the restoration has

 finished.   Default start value is 25, stop 40, F-1 01-10,

F2 00-30, F-3 00-30, correction=000

Failure recovery:

1. No reaction after power supply, no lightening of the

screen
Check whether the socket has electricity by using

other electrical devices with the same plug. If there

 is electricity, check whether the temperature

controller has been powered off, then you can

press SET once for power-on.

2. The screen can display, but cannot realize

 temperature control function
If the temperature is correctly set, yet both start

and stop fail, the reason might be there is some

mistake for start and stop setting value.

Please exchange the set value and stop value.

3. Temperature change exceeds the control range
This controller is position control, which means the

red light is on for start, and green light for stop.

If changes of the indication lights during control

are right, yet there is overshoot temperature,

then it means the temperature controller is in

good condition. You can solve the problem by

lowering your heating or refrigeration power.

4. There is some difference between measured

 and actual temperature
The middle part of the controller displays actual

temperature. If you feel the present temperature

is 30 Celsius degrees yet the controller displays

29.6, you can enter temperature correction by

pressing SET power-on to correct the temperature

 as 0.4. if the actual temperature is 31.2, but you

think it is 30, then you can decrease the corrected

value as -1.2 to get the temperature you want.

5. For other failures, please contact us.

Attention:

For the first time to use this product, please carefully r

ead this instruction.
1. This product has three plugs, so please use a socket

 with earth wire.
2. The master engine of this controller is not waterproof,

so pay attention to avoiding water intrusion. Use in

bathroom or outdoors is prohibited.
3. The use power is not supposed to be higher than

the rated power of this product, or else it may lead to

permanent damage and danger.
4. For actual temperature control, please do not

leave before you check whether temperature control is

performing in the right way.

فيديو يوضح عمل الدارة

https://www.youtube.com/watch?v=dNfGwNHBqMY




TH16 12V  دارة تحكم حرارة + رطوبة

Description:

XY-TR01 Temperature and humidity control module high

precision digital display word double output automatic

constant temperature and humidity control panel

Product adopts industrial-grade chip, high-precision

SHT20 temperature and humidity sensor.



Parameter:

Temperature range: -20 -60 Celsius

Humidity range: 00% -100%RH

Control accuracy: 0.1 Celsius, 0.1%RH

Detection probe: integrated sensor

Output type: relay output

Output capacity: maximum 10A

Dimension: 57*60*20mm



Functions:

Temperature function:

1. Automatic recognition of working mode

2. Cooling

3. Heating

4. Temperature correction function

Humidity function:

1. Automatic recognition of working mode

2. Dehumidifying

3. Humidifying

4. Humidity correction function



Remotely reading/setting of parameters

Real-time reporting of temperature/humidity

Relay enable function (enabled by default)



Set Parameter:

1. Working Mode:

The system automatically recognizes the working mode

according to the starting/stopping temperature and the starting/stopping humidity.

2. How to set the starting/stopping temperature function?

Hold press the "TM+"/ "TM-" button for more than

3 seconds to enter the startup/stop temperature

 setting interface. The parameters can be

changed by the "TM+" and "TM-" buttons.

After the parameters are changed, wait for 6s

and it will automatically save and exit.

3. How to set the starting/stopping humidity function?

Hold press the "RH+"/"RH-" button for more

than 3 seconds to set the minimum/maximum

 value of humidity. The parameters can be

 changed by "RH+" and "RH-" buttons.

After the parameters are changed, wait for 6s and

 it will automatically save and exit.


TH14  دارة تحكم حرارة ورطوبة

ZL-7802AL,12VDC,PID  ,temperature & humidity controller ,Multifunctional Automatic Incubator

1. Feature

ZL-7802AL is a 12VDC(power supply and control

output DC 12V)

intelligent temperature and humidity controller

 (High accuracy PID

temperature control can be adopted). Compact design,

IP65 level front panel protection, convenient

operation and easy

installation. Suitable for control of incubator,

climate chamber,

warehouse, and so on.

2. Main Function

  • Temperature and humidity measurement

  • and display

  • heating control (R1)(PID control mode/

  • hysteresis control mode)

  • Dehumidify control/ Humidify control (R3)

  • Ventilation / over-Temperature and

  • humidity limit protection (R2)

  • Timer control (R4 R5) (egg left-turning,

  • egg right-turning)

  • humidity load (R3) delay protection

  • Temperature and humidity calibration

  • Sensor failure warning

3. Size Specification

  • Front panel dimension: 78* 34.5mm

  • Drilling template: 71* 29mm

  • Whole machines dimension: 78* 34.5* 71mm

  • Length of sensor(s): 2m

  • (including the sensor probe)

4. Technical Specification

  •  Power supply:DC12V

  •  Input signal: One humidity and temperature

  • sensor, wire length 2 meter

  •  Output load: R2 R3 R4 R5 load 1A/12Vdc,

  • R1 load 17A/12Vdc.

  •  Setting range: Humidity 0~100RH, step

  • 0.1%; temperature -20120C, step

  • 0.1C

  •  Absolute accuracy: Temperature 1%;

  • humidity 3%(under temperature 20~60)

  •  Working environment: -20-45C, 10-90RH

  • without dew

  •  Protection level: IP65 (front panel)

  •  Case: PC + ABS Fire Proof

  •  Protection Degree: IP65 (front panel)

  •  PCB Lacquered Protection


TH11 دارة تحكم حرارة ورطوبة

EW-330A Constant temperature constant humidity controller

Technical Specification

1. Upper nixie tube is to display temperature or

relevant parameters; lower nixie tube is to display

humidity or relevant parameters;

2. Range of temperature control: -39℃~98.

Resolution: 1; precision: 1. Normally, current

temperature measured is displayed. Heating

or cooling can be set easily. Pick-up of relay: the

indicator light is ON; heating :the indicator light is

kept ON; cooling: the indicator light is twinkling.

3. Range of humidity control: 20%RH98%RH.

Resolution : 1%RH; Precision: 5%RH. Normally,

current humidity measured is displayed. Humidifying

or dehumidifying can be set easily. Pick-up of relay: the

indicator light is ON; humidifying: the indicator l

ight is kept ON; dehumidifying: the indicator light is

twinkling.

4. Three control relays: 1 temperature relay,

1 humidity relay, and 1 fan relay. The fan relay and

temperature relay are synchronous.

5. Temperature transducer: 10k2 m 1 piece;

humidity transducer: 1.8m 1 piece




TH10  دارة تحكم حرارة ورطوبة

WSK303 96*96mmTemperature and humidity Controller with sensor LED Digital display AC220V

Technical Index :

Supply voltage : AC Switching power supply

 85V~265V, 50~60Hz

AC Transformer : 110V, 220V, 380V, 50~60Hz

DC  24V, 36V, 48V, 110V, 220V

Accuracy class : Temperature  0.5C

Humidity  5%RH

Resolving power  14 Bit

Cycle of sampling  0.5 Sec

Measurement range Temperature -40~100C

Humidity 0~100%RH

Display Measured values and set values by LED

Output condition and alarming condition by LED lights

Way of operating Controlling by two-step (settable

turn difference)

Control output Relay output

Contact capability 250VAC 3A (Resistive load)

Voltage pulse output 0~12 (Suitable for solid relay SSR)

Output contact

Electrical endurance 110 times

Mechanical durability: 110 times

Installation Panel type and embedded

Weight

About 0.5Kg (The power supply of product is the switching power supply)




TH08 وصلة كهربائية + دارة تحكم حرارة ورطوبة



THC-220 Plug Digital Temperature Humidity Controller Thermostat Regulator Control

Switch LCD AC220V 10A for Green House




TH06 دارة تحكم حرارة ورطوبة

YK-301 electronic temperature controller and humidity display refrigerator Egg incubator

digital thermostat



Technical Parameters:

1,Power:12V Outer transformer

2,Temperature sensor:NTC-103,1pcs,2M length,not

separate     with positive and negative

3,Humidity sensor:1pc, humidity display range:00-99%

    Accuracy 03%

4,Temperature display range:-45C~80C   Accuracy 01C

5,Temperature control range:-45C~80C      factory set 0.5C

6,Outsize:176mm(L)41mm(W)43mm(D)

    Hole size:138mm(L)32.5mm(W)

7,Working temperature:-10~60C ;RH:20% ~90%

(non condensing)

8,Relay touch volume:compressor:30A/250VAC

   Lighting:10A/250VAC Fan:10A/250VAC


TH04  دارة تحكم حرارة

10A 12V Digital Temperature Controller

Specifications:
Working voltage: 12V 10%
Rated current: 10A
Power consumption: ≤3W
Measurement range: -40~120 Celsius degree
Measurement precision: 0.1 Celsius degree
Measurement error: 0.5 Celsius degree
Control range: -40~120 Celsius degree
Control precision: 1 Celsius degree
Working temperature:-20~70 Celsius degree
Temperature sensor: NTC 25 Celsius degree=10K B3435
Item size: 8.5*7.5*3.5cm / 3.4*3*1.4in
Item weight: 87g / 3oz
Package size: 11*8.5*4.3cm / 4.3*3.4*1.7in
Package weight: Approx. 125g / 4.4oz




TH03 دارة تحكم حرارة

Digital display temperature

controller B-001

Working voltage:AC220V, 50 ~ 60 hz

Load current:10A

Temperature measurement range:-50~+70

The environment temperature:-10~60

The whole machine size83.5*40.5*63mm(L*W*H)

Installation dimensions:71*29mm
TH01  دارة تحكم حرارة

B-010 Microcomputer Temperature Controller

B - 010 type microcomputer temperature controller

is based on single

chip microcomputer as the core controller.Suitable for

cold storage, freezer, such as automatic temperature control.Concise and packaging design, and give 5 meter

 long temperature sensor.

Product Name

Digital Display

Temperature Controller

Type

B-010

Voltage

220VAC,50HZ

Measurement Error

1

Measuring Range

-50~+50

Weight

0.210kg

Hole Size

71mm*29mm

Panel Size

75mm34mm

 Lower Limit L

-50 ~+49

Upper Limit F

-49~ +50

Controling Type

Temperature

Control ModeJ

RefrigerationCC,HeatingHH

Power consumption of the machine

≤2W

Temperature Measurement Precision

1

Relay Contact Capacity

250VAC,10A(resistive)Transformation Output

Instrument Working Power Supply

220VAC,50HZ,Power Consumption is less than 2 w

Temperature Display Resolution

1

1. Temperature measurement,display and control

2. Temperature lower limit and Upper limit set,Open and stop control of the equipment

3. The controller used in refrigeration, compressor stop delay time setting and control

4. Two kinds of controlled cooling and heating mode

5. Temperature sensor failure display (open circuit or short circuit)

6.The controller of temperature measurement using software correction, ensure accuracy of temperature measurement in temperature measuring scope, without user fixed temperature.










TH65   دارة تحكم حرارة ورطوبة للفقاسات

XY-WTH1 DC 6-30V Digital Display Constant

Temperature Humidity Incubator Controller

Dual Thermostat For AC 220V

Temperature control: -20~60℃
Humidity control: 0~100%RH




TH64 XK-W1099  12V   دارة تحكم حرارة ورطوبة

للفقاسات والمشاتل وغرف التبريد ومستودعات المواد الغذائية ..

تتحكم بدرجتي حرارة ضمن المجال ناقص ٥٠ درجة وحتى زايد ١١٠ درجة ..

تعمل على البطارية 12V

لأي استفسار رسالة واتس الى قسم المبيعات

0969515995



Power Supply:12V

Temperature control range: 0~100C

Humidity control range: 1~99%RH

Control accuracy: 1C / 1%RH

Sensor: temperature humidity sensor

Output: Max 10A ,power output directly

Size:100mm(L)*55mm(W)*32mm(Depth)

فيديو :  https://www.youtube.com/watch?v=AlXhB69m7W8



https://www.youtube.com/watch?v=5wz-TDn8Mc8




TH62  دارة تحكم حرارة ورطوبة

SHT2000 Thermostat Temperature Humidity

Control   12V

Temperature range: -20~60C
Humidity measurement range: 0%~100%RH
Temperature measurement accuracy: 0.3 C
Humidity measurement accuracy: 3%
Output control: relay output
Output power: MAX 10A


TH61 دارة تحكم حرارة

XY-T01 Digital Thermostat

        -50C  -   +110C

 فيديو طريقة العمل :

https://www.youtube.com/watch?v=ebY-QpoatXM


TH60  12V  دارة تحكم حرارة ورطوبة

STC-3028 KT100 Digital Temperature Humidity Controller

Power Supply

 DC 12V

Temperature Control Range

0C~+100C

Humidity Control Range

00%RH~100%RH

Accuracy

+/-1C 0.1%RH

Relay Capacity

10A/240V AC


TH57   دارة تحكم حرارة



Model: W1209S

Temperature Control Mode: ON / OFF

Temperature range :-50-120C

Resolution: 0.1C (-9.9-99.9C); 1C

(other temperature range)

Measurement Accuracy: 0.1C

Control Accuracy: 0.1C

Return Difference Accuracy: 0.1C

Refresh Rate: 0.5S

High-temperature Protection: 0-110C

Input Voltage: DC 12V

Measuring Inputs: NTC (10K 0.5%)

Waterproof type sensor

Output: 1 Way Relay,

Capacity: 20A 125V AC, 20A 14V DC

Environmental requirements: -10-60C ,

humidity 20% -85%

Power Consumption:

Static current: ≤35MA, attract current: ≤65MA

Power Supply: 12V 200MA



Code

explain

Setting Range

Factory Setting

P0

Heating/Cooling

H/C

C

P1

Return Difference

0.1-30

2.0

P2

Set Limit Max.

+120

120

P3

Set Limit to the Min.

-50

-50

P4

Temperature Correction

-10~10

0

P5

Delay Start

0-10

0

P6

High Temperature Alarm

120

OFF

P7

Data Lock

ON-OFF

OFF

P8

Factory Reset

ON-OFF

OFF


TH56 دارة تحكم حرارة ورطوبة

12V Digital Temperature

Controller W2809

Celsius or Fahrenheit
Wide temperature range
Dual mode for heating or cooling applications
Configurable return difference
Calibration offset
Start delay
Temperature range: -50 ~110 Celsius
Accuracy: +/-0.1 Celsius
Control accuracy: 0.1 Celsius
Refresh rate: 0.5 seconds
High-temperature protection: 0-110 Celsius
Input voltage: DC 12 v
Measuring inputs: NTC (10K 0.5%)

waterproof sensor
Output: 1 way 20 A relay
Environmental requirements:

 -10-60 Celsius , humidity 20% -85%RH
Power consumption: Static current: less

 than or equal to 35 mA,attract current: less than

or equal to 65 mA
Power supply: 12 v 200 mA




TH53 دارة تحكم حرارة

XH-W1219 Dual LED Display Thermostat

Temperature Controller Module Sensor DC 12V

Instructions:
1. Please pay attention for your first use.

You need wait 6s after your setting data,

the module will save the date you have

set after 6s.
2. Short press button SET: If you start the

time setting mode , Nixie tube will blink.

You could adjust the time T1 and T2 by

button+ and button-. Please wait 5s after

your setting date, the module will save

 the date you have set after 5s
3. Long press button SET: if you start the

parameter setting mode. There are two

group parameter for your choice : P0 and P1.

 You could switch P0 or P1 by short press SET.

Under the parameter P0 and P1,you could set the

timing mode by the button+ and button-.

P0--0: timing mode is 0--999 seconds
P0--1: timing mode is 0--999 minutes
P0--2: timing when the pattern is 0--999
P1--0: T1 time delay relay (T1 timer)
P1--1: T1 delay time relay releases (T1 timer)
P1--2: time delay relay after T1 (T1 timer), then

the delay time T2 successor electrical release

(T2 timing) ends.
P1--3: T1 delay time relay releases (T1 timer),

then the delay time T2 successor Electric

energized (T2 timing) ends.
P1--4: time delay relay after T1 (T1 timer),

then the delay time T2 successor electrical

release (T2 timer), repeat the cycle.
P1--5: T1 delay time relay releases

(T1 timer), then the delay time T2

successor Electric energized (T2 timer),

repeat the cycle.


TH51  دارة تحكم حرارة

XH-W1411 12V 10A Digital Temperature

Controller  range: -55- + 120C

SET Function switch/ startup &shutdown

Under the state of start-up ,press SET button

three seconds for startup & Shutdown, if it is

power-off after shutdown, it will keeping

state of shutdown when power-on again.

During the normal use .  pressing SET

button switch into F-1 (Discontinuous operation) ,

F-2 (regularly shutdown),F-3 (regularly startup) ,

switch function (F1-F3 is additional function of use ,

it is no influence to set temperature controller

F-1

Discontinuous operation  start minute setting on the left side  stop minute setting on the right side

F-2

Timed shutdown. hours on the left .minute on the right  Max timing range:

F-3

Timing startup  . hours on the left   minute on the right



  Temperature correction

Unplug the thermostat ,press SET button

to be power-on, enter into temperature

correction function. Screen displaying---000----.

Increase or reduce temperature based on

temperature before corrected. Max range is -9.9-99,

Completed the correction ,Actual

temperature=value of before correction

temperature +correction of value.

Self-checking function

Press the left temperature setting button ▲▼ at

 the same time to be power-on then enter

into self-checking function.

Restore factory setting.

Press the left temperature setting button ▲▼

at the same time to be power-on ,

screen displaying 88-888-888,Completed

restore factory setting after buzzer alarmed


TH48  جهاز تحكم حرارة ورطوبة مدجنة

XM-18G Automatic Incubator Controller    Temperature And Humidity Detectors


TH47  جهاز تحكم حرارة ورطوبة مدجنة

XM-18E Automatic Incubator Controller   Temperature And Humidity Detectors

فيديو توضيحي :

https://www.youtube.com/watch?v=xOoQGUPD-Jw


TH46  جهاز تحكم حرارة ورطوبة مدجنة

XM-18 Automatic Incubator Controller

 Temperature And Humidity Detectors

Main Technical Index:
1.Temperature Measuring Range: 0-40.5

degrees Celsius
2.Temperature Measurement Accuracy:

0.1degrees Celsius
3.Humidity Measurement Range: 0-99% RH
4.Humidity Accuracy:  3% RH
5. Number of signal-output: 7, (over-temperature,

 temperature control, insufficient temperature,

 egg left-turning, egg right-turning, humidity control,

 alarm)
6.The maximum output load current:

temperature control, insufficient temperature

 8.A / AC220V, over-temperature, egg left-turning,

egg right-turning, humidity control, alarm  1A / AC22
7.Number of egg-turning: the maximum record is

999 times.
8.Cycle of egg-turning: adjustment of 0 - 999 minutes

(the factory default is 90 minutes)
9.Egg-turning time: adjustment from 0 to 999 seconds

(the factory default is 180 seconds)
10.Ventilation cycle: from 0 to 999 minutes
(The factory default is 120 minutes)
11.Ventilation time: from 0 to 999 seconds

(the factory default is 30 seconds)
12. Temperature measurement line length:

about 2 meters
 Accompanied by an English document

(6, tells you in detail how to use, simple operation)



XM18G



XM18E


TH25      دارة تحكم بالحرارة

XH-W1209  Temperature Control Module ,

Water Heat Control  0~110C


TH24    12V  مقياس حرارة رقمي

 -50 ~ +110 c  مجال القياس


TH23  W3230 دارة تحكم حرارة

DC 12V Digital Temperature Controller

 Switch Sensor Meter -55-120

℃







Specifications:



  • Power Supply:12V DC,

  • Temperature Control Range:-55-120

  • Resolution Ratio: 0.1C(-9.9-99.9); 1C

  • (other range)

  • Color of Displaying: red/blue

  • Measurement accuracy: 0.1C

  • Control accuracy: 0.1C

  • Sensor: NTC10K Waterproof sensor

  • Output: Relay Contact Capacity 10A 220V ,

  • 20A 12V , 20A 24V

  • Environmental requirements: -10-60C ,

  • humidity 20%-85%RH

  • Dimension:79mm *43mm*26mm

  • Cutting Size:73mm*39mm


TH20 دارة تحكم حرارة

12V  Digital Temperature Controller

10A XH-W3002

Specification:

Supply voltage: 12V/24V/220V.

Temperature range: -50-120 degrees.

Range of temperature control: -50-120 degrees.

Temperature control accuracy: + 0.1 degrees.

Temperature measurement accuracy: + 0.2 degrees.

Load power: 120/240/1500W.

Measuring input: NTC10K waterproof probe L=1 M.

Output type: direct output.

Output capacity: maximum 10A.




TH19 ZFX-W1012   دارة تحكم حرارتين

Measuring range: -50 ~ 99

Measurement accuracy: 1 (-50 ~ 70)

Resolution: 0.1


TH18    SHR04A   SENSOR

  حساس حرارة ورطوبة فقاسة بيض


TH17 دارة تحكم حرارة ورطوبة عالية الجودة

ZL-7928A, 220Vac + 12V Battery backup,

Dry outputs, Multifunction Automatic

Incubator Controller

Feature:

ZL-7928A is an inelligent temperature and

humidity controller, safe and stable,

convenient to operate, applicable for

controlof incubator, climate chamber,

warehouse, and so on.

Specification

Power supply: 100~240Vac, 50/60Hz, and/or

11~26Vdc. When 110/220Vac present, the 12/24Vdc

is backup. When 110/220Vac disappears, 12/24Vdc

supplies power. One temperature sensor(L = 2 meter),

 one humidity sensor (L = 2 meter). Display range:

Humidity 0~ 99% RH. Temperature -9.9~ 99℃.

Measuring accuracy: Humidity 3%@25℃.

Temperature 1%@25℃. Output control:

main-heater<heat1>, aux-heater<heat2>, lamp,

humidity<wet>, egg-right-turning, eg-left-tuming,

fan. Output load (rated value): main-heater

and aux-heater. 10A; Lamp, Humidity, egg-tuming

and fan: 5A. Special loads, such as tungsten lamp,

switching power supply module, etc., please

contact provider. Hatched day counter. the

maximum value is 99 days. Egg tur control:

Turn period: 1 ~ 999 minutes. Turn driving time:

0~ 999 seconds. Turn times counter.0 ~ 999 times.

Air exhaustion control: Period: 1 ~ 999 minutes.

Exhausting time: 0~ 999 seconds. Lamp control:

Period: 1 ~ 999 minutes. llmiating time: 0 ~ 999

seconds. Operation environment: -10 ~ 45C,

 less than 90% RH without dew. Device

dimension: 160 * 80* 95 mm. Installation drling

size: 151.5 * 76.5 mm.


TH15  دارة تحكم حرارة ورطوبة عالية الجودة

ZL-7918A, 100-240VAC, Multifunctional

Automatic Incubator controller ,

1. Feature

ZL-7918A is an intelligent temperature and

humidity controller, safe and stable, convenient

to operate, applicable for control of incubator,

climate chamber, warehouse, and so on.

2. Main Function

  • Power supply: AC100~240V 50/60Hz
  • One temperature sensor (L=2M), one
  • humidity sensor (L=2M)
  • Setting range: Humidity 10~80% RH.
  • Temperature 1~65
  • Display range: Humidity 0~99%RH.
  • Temperature -20~80
  • Measuring accuracy: Humidity3%
  • (under temperature 20~60).
  • Temperature1%
  • Output control: 7 outputs (heater,
  • aux-heater, fan, egg left-turning,
  • egg right-turning, humidity, illumination)
  • Output load: heaters ≤ 1500W.
  •  Illumination ≤ 100W. Humidity, fan
  • and egg turnings ≤ 1A/250Vac
  • Hatching day record: the maximum
  • record is 99 days
  • Egg-turning control: Period: 1~999 minutes.
  • time: 0~999 seconds. Turning times: 0~999 times
  • Ventilation control: Period: 1~999 minutes.
  • Ventilating time: 0~999 seconds
  • Illumination control: Period: 1~999 minutes.
  • Illuminating time: 0~999 seconds
  • Operation environment: -10~45, 90%RH
  •  without dew
  • Device dimension: 160 * 80 * 95 mm
  • Installation drilling size: 151.5 * 76.5 mm

TH13  دارة تحكم حرارة

YK-1840A New Programmable digital

temperature controller Refrigeration

Defrost cold-chain industry incubator sensor thermostat

Features|:

*refrigeration, defrost, on/off, lock the keyboard,

single sensor, temperature calibration

*internal/external version

*refrigeration/ heating switch

*manual/automatic defrost; time/ temperature defrost

*over temperature alarm

*press the bottom to turn on/off

*30A relay support, 30A can be applied directly to 1 compressor

*restore factory settings, set memory, self-diagnosis



 Parameters:

Control range: -45-80C

Working voltage: 220VAC/ 110VAC

Compressor: 30A/220V/AC

Lighting: 10A/220V/AC

TH12 دارة تحكم حرارة

XH-W1308  Adjustable Digital Cool

Heat Sensor Red Display Temperature

Controller   DC 12V

Specifications:
Control Temp Range: -50-120℃
Power Requirement: DC/AC 12V
Resolution: 0.1℃
Measuring Input: NTC(10k 0.5%) waterproof sensor 0.5m
Relay Output: 1 way
Rated Current: 10A
Control Accuracy: 0.1℃
Hysteresis Accuracy: 0.1℃

Refresh Time: 0.5s
Power consumption: Static current<=35MA,
Display Type: 0.28" 3 digits display tube
Environmental Requirement: -10-60℃, humidity: 20-85%
Size: Approx. 10cm x 4.8cm x 2.5cm/ 3.94" x 1.89" x 0.98"


TH09

  دارة تحكم حرارة ورطوبة للمداجن والفقاسات والبيوت الزراعية

ZL-7901A,100-240VAC,PID,Multifunctional Automatic Incubator, incubator controller, temperature controller for incubator

1. Feature

ZL-7901A is an industrial intelligent temperature

and humidity controller. It can connect SSR external

output and adopt PID to control temp with high

precision. It use easy touched button and big LCD

display, convenient operation and easy installation.

Applicable for control of incubator, climate chamber,

warehouse, and so on.

2. Main Function

  • Temperature control, three combination
  • output, PID high precision control is chosen.
  • Humidify and dehumidify control
  • Time air exchange control
  • Time egg turning control
  • Illumination control
  • Node alarm output
  • Auto restart function
  • Temperature/humidity over limit warning
  • and protection function
  • Temperature/humidity sensor fault warning
  • and protection function

3. Specification



  • Setting range: humidity 0~100RH,
  • temperature 0~100℃
  • Measuring accuracy: temperature 1%,
  • humidity 5%
  • Working environment: -20~45℃,
  • 10~90RH no dewing
  • Size: 137*89*56(mm)
  • Hole size:122*75(mm)

TH07  دارة تحكم حرارة

YK-181 digital  temperature controller display refrigerator with Sensor Thermostat for

Dishwasher 220v/30A 10A

Suitable for seafood, fish, cold water machine, engineering machine and cold storge, refrigeration engineering built-in transformer/delay protection/automatic fault diagnosis function

color

black

brand

YOUKONG( OEM, ODM)

tempeature range

 -45~80C

resolution

1C

accuracy

1C

connecting line length

1.5meter/ 2.0meter (Customized support)

material of probe

plastic

display

lcd display, celsius

style

internal version, nonwaterproof

working voltage

AC220V 10% 50HZ/60HZ

output load

10A 30A/220VAC

power consumption

less than 3W

input signal

one temperature sensor

machine size

76*35*76mm

hole size

71*29mm

packing

color box


TH05

 دارة تحكم حرارة ورطوبة مع مخرج لتسجيل التغيرات الحاصلة

 خلال زمن معين

YK-525 medicine cabinet temperature and humidity controller and data logger with USB

Functional features:

Humidity, temperature control/show/frost/lighting/

fan control/set the power switch/memory/since

the diagnosis



  Technical parameters:

  1, power supply: 12 v external transformer

    2, temperature probe: NTC - 103, 1, 2 meters long, regardless of positive and negative

   3, humidity probe: 1, humidity display range: 00-99% plus

       or minus 03% accuracy

  4, the range of temperature display: - 45 C ~ 45 C

       accuracy + / - 01 C  - 49 F~ 113 F

  5, temperature control range: - 45  ~ 45 C factory

       value 5 C

  6, appearance size: 176 mm (length) x 41 mm (width)

       x 43 mm (deep)  Hole size: 138 mm (length)  x 32.5 mm     (wide)

 7, working environment temperature: - 10 ~ 60 C

      Relative humidity: 20% ~ 90% (no condensation)

 8, relay contact capacity: compressor: 30 a / 250 vac,

      the rest: 10 a / 250 vac


TH02  دارة تحكم حرارة

AC110-240V LED Digital Temperature Controller

All-Purpose  Thermostast 2 Relay thermal regulator

With NTC SensorTemperature Alarm



Specifications:
Working Voltage: AC 110-240V
Rated Current: 10A
Measurement Range: -50 to 110℃
Temperature Resolution: 0.1℃
Control Accuracy: +/- 0.1℃
Refresh Frequency: 0.5S
Environmental Requirements: -20 to 70℃; 20% to 85%

(Humidity)
Temperature Sensor Cable: 2M / 78.74"
Item Size: 7.5 * 8.5 * 3.5cm / 2.95 * 3.34 * 1.38"
Item Weight: 108g / 3.8oz(110-240V)
